Hundegger SPEED-Cut
Precise and flexible timber processing - high performance 5 axis cutting machine
Tasks such as cutting simple timber elements quickly and precisely – without measurement, without marking, without setup – and, optionally, more extensive milling and drilling operations: this is exactly what the SPEEDCut has been developed for.
The SPEED-Cut operates at a previously unmatched speed. The heart of the machine is the flexible saw unit which can make cuts at any angle and inclination.
Whether it is one-man company or a larger producer: The SPEED-Cut is ideal for all timber construction companies. Every machine is specified to the individual needs of the customer – from a simple 5 axis cutting machine to a large CNC processing center.
For cross-sections from 20 x40 mm to 240 x 480 mm.
Suitable for processing Timber frame, Roof truss, KVH, Glulam, IJoist. LVL materials, and solid timber components.
Flexible thanks to a modular system
The SPEED-Cut has enormous potential even in its basic configuration level. The saw unit alone can perform a wide variety of different processing operations in addition to simply cutting materials to length. And if you need more:
The modular design means that the standard machine can be extended at any time and equipped with additional units. Drilling, milling, slotting, marking, labelling – the SPEEDCut can do everything and quickly.
THE HIGHLIGHTS OF THE SPEED-Cut
Two independently operating conveyor systems position the workpieces and ensure fast and precise timber handling. The advantage is a short throughput time without adjustment or retooling.
The SPEED-Cut processes timber cross-sections of 20 x 40 mm to 240 x 480 mm in any timber length. It is also possible to reliably transport and precisely process several stacked workpieces without having to retool.
If desired, the SPEED-Cut can cut the rest wood produced during the cutting process into firewood-sized pieces. Chips and waste wood fall down into the disposal channel. From there, they are transported effectively out of the processing zone by means of a transport conveyor belt integrated in the machine outfeed.
The 5 axis saw unit
This powerful 5 axis saw unit is standard equipment of the SPEED-Cut. Whether jack rafter cuts, hex cuts, regenerative cuts or diagonal cuts: The pivoting saw performs all types of saw cuts fully automatically and with millimeter precision – at any angle, at any inclination and in all lengths.
Turret mill
A universal unit that can be equipped with up to 4 tools. It can be used for many different processing operations: Wichert truss joint or scarf and key joint, roof ridge joint, offsets, birds mouths, tenons at all positions, concealed recessing, and many others. Use the turret mill for boring holes, making tenons or machining mortises on the end of the timber components.
Collection conveyor for small parts
This allows even the shortest parts to be reliably separated from offcuts and transported out of the machine. This means more yield from otherwise waste wood.
- Any timber length
- Connectable to infeed systems
- Automatic timber discharge
- Data interface
- Upgradeable
VIDEO SPEED-Cut 480
Download
Processing examples SPEED-Cut
Flexibility and precision at highest speeds
HIGH-PERFORMANCE CUTTING
When cutting girder parts or timber frame construction parts an unparalleled speed is achieved at full flexibility and precision.
FAST CUTTING WITH MANY OTHER PROCESSING POSSIBILITIES
Tsks such as cutting simple timber elements quickly and precisely – without measurement, without marking, without setup – and, optionally, more extensive milling and drilling operations: this is exactly what the SPEED- Cut has been developed for. The saw unit with flangeless saw blade can be rotated through 360° and pivoted by 90°. The unit is therefore able to move underneath the supporting side of the workpiece to also allow birdsmouths, eave cuts or stair stringers to be cut.
FLEXIBLE THANKS TO A MODULAR SYSTEM
The SPEED-Cut has enormous potential even in its basic configuration level. The saw unit alone can perform a wide variety of different processing operations in addition to simply cutting materials to length. And if you need more:
The modular design means that the standard machine can be extended at any time and equipped with additional units. Drilling, milling, slotting, marking, labelling – the SPEEDCut can do everything and quickly.
Fast cutting with many other processing possibilities.
Produce more flexibly with the compact, high-performance cutting machine
VARIANTEN
Cross-sections of 20 x 40 mm to 240 x 480 mm in any timber length.
The modular design means that the standard machine can be extended at any time and equipped with additional units. Drilling, milling, slotting, marking, labelling – the SPEED-Cut can do everything and quickly.
Main units
An unbeatable duo:
5 axis saw unit and turret mill
Options
In addition to the basic equipment, the SPEED-Cut offers various additional options.
Installation variants, according to your needs
21.0 m space requirement of the SPEED-Cut with a wood length of 8 m on the infeed and outfeed side.
Automation of the Hundegger SPEED-Cut
Flexible thanks to a modular system
There are various automation options for the SPEED-Cut machine.
Furthermore, this machine is part of the fully automatic "HUNDEGGER TrussLinc®” production line.
Automatic infeed
The operator can place several pieces of timber at the same time on the infeed cross conveyor with buffer stainless-steel slatband chains.
The system automatically feeds these pieces of timber to the processing zone separately and without damage.This allows the operator to perform other tasks.
Hydraulic lift table
The hydraulic lift table is installed upstream of the infeed cross conveyor.
Stacks of timber can be placed on the lift table and raised to the desired height.
This enables timber to be fed in continuously level with the infeed cross conveyor.
Part discharge
A cross conveyor system with roller rails provides buffering of the finished workpieces at the machine outlet. If required, the parts can also be transported further with a cross conveyor.
Disposal of chips and waste wood
Chips and waste wood fall down into the disposal channel. From there, they are transported effectively out of the processing zone by means of a transport conveyor belt integrated in the machine outfeed.
