Hundegger K2-Industry
The industrial high-performance class with maximum availability.
K2-Industry sets completely new standards in performance and flexibility for industrial joinery.
Our engineers have done a fantastic job and developed a completely new machine generation. Every detail and each component is uncompromisingly designed for high-performance 3-shift operation.<br/> The new K2-Industry brings a significant leap in performance for every user, and as a new high performance system in the series of Hundegger joinery machines, redefines the state of the art.
Machining timber flexibly and efficiently without measuring or marking and without setup changes – the new K2-Industry makes this possible for all timber construction companies that value maximum productivity from carpentry joinery through to log house construction.
Whether you choose series or one-off production, the new K2-Industry always offers maximum flexibility and speed. Tool changeover times become a thing of the past. The machine is ready for operations of all types: from conservatories with small cross-sections to glulam and CLT measuring 300 x 1,300 mm.
Round timber, log home profiles, T-sections and multiple layers (stacks) are also handled rationally and processed accurately without changes to the machine setup.
The three base models of the K2-Industry with different processing widths:
- Joinery machine K2-Industry 450 - from 20 x 50 to 300 x 450 mm - the basic machine for every carpentry business
- Joinery machine K2-Industry 650 - from 20 x 50 to 300 x 650 mm - for the trend towards larger timber cross-sections
- Joinery machine K2-Industry 1300 - from 20 x 50 to 300 x 1,300 mm - for all requirements up to the joinery of laminated girders and cross laminated timber
HIGHLIGHTS OF THE K2-Industry
Whether you choose serial- or one-off production, the new K2-Industry always offers maximum availability and speed. Tool changing times become a thing of the past. The machine is ready for operations of all types: from conservatories with small cross-sections to laminated timber measuring up to 300 x 1,300 mm.
New sawing unit
13 kW sawing unit and open sawing table for the disposal of trim cuts
5-axis universal mill
Power and precision with up to 35 kW.
Horizontal saw
Slotting at highest quality and maximum throughput.
6-axis unit
Full power with 12 kW and infinitely variable speed range for maximum versatility.
Trenching unit
Perfectly coordinated high-performance unit for operations in modular construction.
Synchronous unit
Simultaneous processing on two opposite part sides for maximum productivity.
- High performance timber processing
- Unmatched flexibility for bespoke projects
- Vast variety of processing options
- High precision and reliability
- Developed for the continuously operation in 3 shifts
THE K2-Industry HANDLING SYSTEM
The revolutionary handling system of the K2-Industry with two clamping carriages fixes the timber directly at the processing zone. This ensures maximum precision even for the processing of slightly bent timber, round timber and log home profiles. T-sections or multiple layers (stacks) are also handled rationally and processed accurately without changes to the machine setup.
This leads to a new dimension in efficiency.
VIDEO K2-Industry
Holzbau Träume mit X-Cam | Hundegger
Download K2 Industry
K2-Industry machining examples
Flexibility on top form
MAXIMUM PROFITABILITY IN CARPENTRY JOINERY
In carpentry joinery, the central challenge is to process timber flexibly and efficiently without measuring, marking or changeover times. The new K2-Industry offers all timber construction companies maximum productivity and availability, from carpentry joinery through to log house construction.
Without any retooling, the K2-Industry also processes and transports round timber, log house profiles, T-sections and multiple layers, for example. Even with just the standard equipment, most parts needed in carpentry joinery can be produced perfectly.
The high flexibility is one of the K2-Industry’s strengths. Whatever is needed in carpentry joinery can be produced quickly and cost-effectively.
If more complex tasks are to be performed, the K2-Industry can be freely equipped with the necessary additional units and extended as required at any time.
IMPRESSIVE EFFICIENCY IN TIMBER FRAMING
The particular challenge in half-timber construction is the visible timber framework and the use of special materials such as oak. The use of historical connection elements, often with regional characteristics, requires the use of high-performance technology, particularly in the case of restorations, because in addition to first-class results, the focus is also always on economic viability. For these application scenarios, the K2-Industry has a comprehensive range of standard units and special solutions.
HIGHLY EFFICIENT IN MODULAR CONSTRUCTION
With the K2-Industry, the precision that is so crucial for modular assembly can also be achieved for twisted or warped raw timber – while simultaneously ensuring highest speeds.
DEVELOPED FOR LOG HOME CONSTRUCTION
The log house unit will give your log house production a real boost!
With two vertical and two horizontal milling units for quadruple rabbeting of log house planks. Available up to 4 x 22 kW, depending on the version. One unit with many possibilities: Performing two opposite milling operations at the same time – or allowing the four milling units to operate independently of each other, set to the desired milling depth. This also allows rabbeting to be performed on one, two or three sides. The stroke is effected hydraulically. Hundegger manufactures the profile milling cutters for the log house unit according to the specific needs of the customer.
PERFECT FOR PROCESSING CROSS LAMINATED TIMBER
With a processing width of 1,300 mm, the K2-Industry provides a highly productive solution for joining laminated timber panels.
Machining of the increasingly popular cross laminated timber requires units that are perfectly tailored to these needs. With the new K2-Industry, special units have also been developed for these applications. For example, a vertical and horizontal turret mill, a horizontal saw, a pivoting deep-hole drill unit or special slot cutters which enable the requirements in cross laminated timber joinery to be perfectly met. The K2-Industry concept enables 6-sided processing in a run - maximum economic efficiency is guaranteed.
FLEXIBLE FOR PROCESSING GLULAM
The production of glulam requires a joinery machine with very special qualities.
The K2-Industry impresses with the following advantages:
- Robustness even for heaviest parts
- Absolute precision, even for excess lengths
- Comprehensive range of standard and special units
As a result, the K2-Industry is the absolute benchmark for this area of use.
Modular design
For your optimal performance boost
VARIANTS
The machines thanks to their modular construction can be retrofitted with units at will and expanded, if necessary, at any time. From the simple joinery machine to the fully loaded high-speed version, each version is possible.
Main units
For each operation, a specially developed unit is provided with tools tailored to that unit.
The result: maximum performance without tool changeover times.
Options
With our value-adding options, you can further increase the efficiency of your processes.
Hundegger Cambium software
The software that grows with the tasks you perform
The best mechanics only work as well as the associated software
To ensure this, Hundegger places great importance on a software development department that is integrated within the company. This leads to solutions that are perfectly adapted to customer requirements and that are also continuously developed and maintained. To ensure that our customers continue to benefit from this after their purchase, it goes without saying that we provide software updates. The new Hundegger 3D program CAMBIUM® is characterized by simple data input specifically adapted to the needs of timber construction, as well as a high level of user-friendliness.
GROW MORE EASILY. With CAMBIUM
With the new CAMBIUM software solution, we have created a unique common platform for all our machines and systems. Gone are the days where every machine line needed its own software. This new software also means that time-consuming training for different machines as well as machine-specific updates are a thing of the past. And with CAMBIUM you will in future be able to freely decide where your job preparation workstation is located: Slimline and sleek directly at the machine or in your office – wherever you need it. With so much flexibility, it goes without saying that recalculation is of course also an integral part of CAMBIUM. Nothing is more inspiring than performing your daily tasks with CAMBIUM. It will make you more successful, faster and more precise in whatever you do.
Efficiency
CAMBIUM makes day-to-day work easy and efficient. It covers every wood construction application and interfaces with every Hundegger machine through the bvx2 file.
Optimization
As a highly intelligent solution, CAMBIUM optimises all part types according to your specific needs and always delivers the respective
calculation result fully automatically.
Flexibility
Automatic yet flexible.
As automatic as it is flexible: The intervention possibilities are global; even projects, nestings and parts can be adapted according to the specific processing strategy.
- One single software for all Hundegger machinery
- Mapping of the entire production process
- Fully automated calculations
- Customizable
- Clearly formatted reports
- Standard IT interfaces
- Able to connect to infeed and storage systems
GROW MORE EASILY. With CAMBIUM
Modular design
For highest flexibility
Automated infeed
The robust infeed conveyer provides extra space for the loading of raw material. The machine separates the individual pieces automatically and gently transfers them to the processing area. In the meanwhile the machine operator can attend to other tasks.
Hydraulic lifting table
The hydraulic lifting table is placed in front of the loading conveyor. Suitable to load whole packs of timber and lift them to the required height. Besides a marked alleviation for your staff it allows for a continuous material flow.
Storage for finished parts
Finished parts will be gently pushed onto a storage rack. The outfeed direction can be adapted to your plant layout. For heavy components an optional chain drive is available to support the discharge. Alternatively the storage rack can be replaced by a conveyor that automatically transfers the finished parts to further work areas.
HUNDEGGER K2-Industry
The range of tasks of the fully automatic Pick & Feed system essentially covers two aspects. On the one hand, it is used to fill the floor storage area, from where the destacking of pre-positioned timber packages with structural timber, cross laminated timber, solid structural timber or TJi beams takes place. On the other, the system also provides the feed to the infeed cross conveyor of a Hundegger joinery or cutting machine or a machining centre.
To fill the floor storage area, the operating personnel set down a raw wood package at the storage location by means of a crane or forklift truck and align it along stops. The layer picker of the Pick & Feed machine is positioned fully automatically above the package and transports it, layer by layer, to a free space in the floor storage area. The SPM-2 is loaded with wallboard, chipboard or OSB panels by means of vacuum technology.
The dimensions of the timber and wood packages, as well as their position is stored by the computer of the joinery or cutting machine and graphically represented on the screen. Finally, the single bar design program retrieves the data of the required cross-sections and lengths for a job from the floor storage information. The layer gripper then transports the required wood packages fully automatically to the infeed cross conveyor, and if raw timber of a layer is not needed, it is deposited back in the warehouse.
